TPLINK 9-Port 10/100MBPS Desktop Switch With 8-PORT POE+

TL-SF1009P New
9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

9× 10/100 Mbps RJ45 ports
8× PoE+ ports transfer data and power on individual cables
Works with IEEE 802.3af/at compliant PDs
Supports PoE Power up to 30 W for each PoE port
Supports PoE Power up to 65 W for 8 PoE ports
Up to 250 m data and power transmitting range under Extend Mode
Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive application
Isolation Mode allows one-click client traffic separation for higher security and performance
Plug and play with no configuration required

Professional 9-Port Unmanaged Switch with 8 PoE+ Ports
Plug and Play, with PoE Transmission for Surveillance up to 250 m
TL-SF1009P

Professional 9-Port Switch with 8-Port PoE+ (65 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 65 W PoE power budget* for the 8× PoE+ ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Plug and Play, No Configuration Required

Ideal for IP Surveillance
Up to 250 m Transmissions
With extend mode, the PoE transmission distance reaches up to 250 m, perfect for IP Camera deployment in large areas.

Ideal for IP Surveillance
Higher Performance and Security
Priority Mode and Isolation Mode make surveillance smoother and safer.

Priority Video Quality Guaranteed
Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.

Isolation Mode Button
One-Click Traffic Separation for Ports 1-8
With one click, Isolation Mode easily divides traffic for ports 1–8 to avoid snooping and tampering. This enables the switch to isolate broadcast storms, improving LAN security and data transmission.

Intelligent Power Management
When total power consumption exceeds 65 W, intelligent power management will cut the lower priority port power. This ensures the high-priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Durable Metal Casing
The interior components of TL-SF1009P are protected by a high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1009P delivers switching performance you can depend on.

Specifications
Hardware Features
Interface :
9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ ports)
AUTO Negotiation
AUTO MDI/MDIX
Network Media :
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
Fan Quantity: Fanless
Physical Security Lock: Yes
External Power Supply : External Power Adapter (Output: 53.5VDC / 1.31A)
Packet Forwarding Rate: 1.3392 Mpps
PoE Ports (RJ45) :
Standard: 802.3 af/at compliant
PoE Ports: Ports 1–8
Power Supply: 65 W
Mac Address Table: 2K
Jumbo Frame: 2 KB
Switching Capacity: 1.8 Gbps
Dimensions ( W x D x H ) : 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Max Power Consumption :
3.6 (220/50 Hz. no PD connected)
77.08 (220/50 Hz. with 65 W PD connected)
Max Heat Dissipation :
12.28 BTU/h (no PD connected)
262.84 BTU/h (with 65 W PD connected)

Software Features
Transmission Method: Store-And-Forward
Advanced Functions:
Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission)
Priority Mode Button (Ports 1–2)
Isolation Mode Button (Ports 1–8)
Mac Address Auto-Learning and Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode

Others
Certification : FCC, CE, RoHS
Environment:
Operating Temperature: 0–40 ? (32–104 ?)
Storage Temperature: -40–70 ? (-40–158 ?)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing

What's in the box
TL-SF1009P
Power Adapter
Installation Guide
