TP-LINK Archer VR1200 AC2100 Wireless Dual Band VDSL/ADSL Gigabit Router

AC2100 Wireless MU-MIMO VDSL/ADSL Modem Router

Super VDSL – The Latest Super VDSL (VDSL2 Profile 35b) tech delivers internet speeds of up to 350 Mbps
Ultra-Fast Speed –Surpasses the Wi-Fi speed limits of the previous generation, reaching up to 1733 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
4×4 MU-MIMO – Simultaneously transfers data to multiple devices for 4x faster performance
Whole-Home Coverage with OneMesh – Co-works with TP-Link OneMesh products to create a flexible and cost-efficient Mesh network
Lightning-Fast Wired Connection – USB 3.0 port and four Gigabit Ethernet ports run up to 10x faster than the previous generation to unleash your home entertainment
TP-Link Tether App – Easily access and manage your network, including remote control and automatic updates, using any iOS or Android mobile device

Get in the Fast Lane
AC2100 Wireless MU-MIMO VDSL/ADSL Modem Router
Super VDSL
Versatile Connectivity
Ultra-Fast Speed
Higher Efficiency
TP-Link OneMesh
Lightning-Fast Wired Connections
Easy Setup

Super VDSL
The Future of Internet Access
The Archer VR2100 features Super VDSL (VDSL2 Profile 35b), the latest generation of DSL technology. Downstream is increased by up to 350 Mbps, 3.5x faster than its VDSL2 predecessor. The integrated DSL port also supports all standard DSL connections.

The Archer VR2100 is compatible with VDSL2, ADSL2+, ADSL2, and ADSL.

Versatile Connectivity
The Archer VR2100 is built to connect you to the internet, no matter your situation. The Ethernet WAN port supports a wired connection to a cable or fiber modem, letting you take full charge of its wireless capabilities as a router. In case your internet goes down, attach a 3/4G adapter to the USB 3.0 port to serve as a backup option so you can get back online in no time.

Enjoy the Network at Full Speed
The Archer VR2100 makes full use of its dual-band Wi-Fi abilities, reaching speeds of up to 1733 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. Enjoy a total speed of up to 2.1 Gbps to eliminate latency and buffering from your HD streams and lag from online games.
Two dedicated Wi-Fi networks support more devices and reduce wireless interference to create stable connections.

4×4 MU-MIMO - Efficient Wi-Fi
for Every Device
MU-MIMO technology serves up to four devices at once, reducing wait time, increasing
Wi-Fi throughput for every device, and making each stream more efficient.

MU-MIMO for Faster
Less Interference
Low Latency

Supports TP-Link OneMesh for Whole-Home Coverage
Co-work with TP-Link OneMesh products, to provide a more flexible and cost-effective Mesh network with a single Wi-Fi name for seamless whole-home coverage.

Lightning-Fast Wired Connections
One USB 3.0 port provides data transfers up to 10× faster than a traditional USB 2.0 port. Connect external storage devices and share files, photos, and videos at high speed. As well as 4 Gigabit LAN ports help wired devices achieve peak performance for HD streaming and gaming.

Easy Setup and Management
Set up the Archer VR2100 in minutes thanks to its intuitive web interface and the powerful Tether app. Manage network settings, including Parental Controls and Access Control, from any Android or iOS device. Tether also provides Automatic Firmware Updates to always give your network the latest performance and security.

Specifications

Hardware Features

Ports: 3 Gigabit LAN Ports, 1 Gigabit LAN/WAN Port, 1 RJ11 Port,1 USB Port
Button: WPS Button, Reset Button, Power On/Off Button, Wi-Fi Button, LED, On/Off Button
External Power Supply: 12V/1.5A
IEEE Standards: IEEE 802.3, IEEE 802.3u, 802.3ab

VDSL2 Standards:
ITU G.993.2, Up to 35b profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)

ADSL Standards:
Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),

ADSL2 Standards: ITU-T G.992.3 (G.DMT.bis),
ADSL2+ Standards: ITU-T G.992.5
Dimensions ( W x D x H ): 8.5 × 6.5 × 1.4 in (216 × 164 × 36.8 mm)
Antenna Type: 3 External Dual Band Antennas + 1 Internal 5 GHz Antenna

Wireless Features:

Wireless Standards: IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency: 2.4 GHz and 5 GHz
Signal Rate: 1733 Mbps on 5 GHz, 300Mbps on 2.4 GHz
Transmit Power: <20dBm (2.4 GHz), <23dBm (5 GHz)
Wireless Functions: Enable/Disable Wireless Radio, Wireless Statistics
Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions
Wireless Schedule: Support 2.4 GHz and 5 GHz Wireless Schedule

Software Features:

Security: NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding
Operating Modes: VDSL/ADSL Modem Router, 3G/4G Router, Wireless Router
Management: Web-Based Configuration (HTTP / HTTPS ), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic Tools, Free Online Firmware Update
DHCP: Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Port Forwarding: Virtual Server, Port Triggering, DMZ, ALG, UPnP
Dynamic DNS: DynDns, NO-IP, TP-Link
VPN : OpenVPN, PPTP VPN, IPSec VPN
Protocols: Supports IPv4 and IPv6
ATM/PPP Protocols: ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP overEthernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
Advanced Features: Parental Controls, Network Address Translation (NAT), Static Routing, RIP v1/v2 (optional), DNS Relay, DDNS, IGMP V1/V2/V3
Guest Network: 2.4 GHz Guest Network, 5 GHz Guest Network
IPSec VPN: Supports up to 10 IPSec VPN tunnels

Others:

Certification: CE, RCM, RoHS
System Requirements:
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, Mac OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Subscription with an internet service provider (for internet access)

Environment:
Operating Temperature: 0?~40? (32? ~104?)
Storage Temperature: -40?~70? (-40? ~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

What's in the box
1 x DSL Modem Router
1 x External Splitter
1 x RJ11 DSL Cable
1 x RJ45 Ethernet Cable
1 x Power Adapter
1 x Quick Installation Guide
