TP-LINK ARCHER AX11000 10Gbps WiFi-6 Tri-Band Gaming Router

TP-LINK ARCHER AX11000 10Gbps WiFi-6 Tri-Band Gaming Router

The outstanding design and engineering in consumer technology CDES Innovation 2019 Award winning Archer AX11000 is a top-notch gaming router which comes with the following.
• The Fastest Wi-Fi 6 Gaming Router – AX11000 speed machine has higher simultaneous transmitting capability that delivers 12-streams Wi-Fi Speeds for over 10 Gbps: 4804 Mbps (5 GHz Gaming) + 4804 Mbps (5 GHz) + 1148 Mbps (2.4 GHz). The router is less congestion for gaming rigs. Armed with Wi-Fi 6, Archer AX11000 becomes the next-level speed machine that offers astonishing Wi-Fi speeds up to 10756 Mbps with an extended range.
o 1024-QAM more data encoding at one time
o 160MHz Channel – the highest channel width on a single stream
o Longer Symbol – clearer signal and more data.
• Game Accelerator – Detect and optimize gaming streams, to ensure your gaming stays immersive and keep your network as fast as your reaction speed.
• Game Protector – Keep your accounts, system and documents safe with the enhanced Homecare™ security system powered by Trend Micro™ delivering comprehensive antivirus protection that ensures your total security while gaming online.
• Game Statistics – Know Your Network: Game statistics shows real-time latency, game duration, system utilization and network resource allocation in a glance with fine-tuned UI elements, puts total control at your fingertips.
• Ultra Connectivity - 2.5 Gbps WAN port and eight Gigabit LAN ports, 2 USB 3.0 in Type A and Type C provide extensive connectivity.
• Powerful Processing – 1.8 GHz Quad-Core CPU and 3 coprocessors ensure your network performance always at peak run.
• Highly Efficient – OFDMA increases the avg. throughput and reduces the lag. More connected devices shall bring more fun rather than dragging the performance. Revolutionary OFDMA is introduced to improve average throughput by 4 times and cut the latency. Take advantage of incredibly low latency to demolish your enemies, with your team crew together.
o OFDMA – Multiple devices share one channel at the same time.
o MU-MIMO – offer 4x4 connections to reduce wait time.
o BSS Colour – keep transmission under overlapped signals.
• Gaming Band - Game on the Fast Lane. Gaming Band - a dedicated gaming band for your 5G_game rigs makes your online games and your families' Netflix 4K streaming no more competitors. DFS expands available channel automatically, get on the more vacant lane and boost the game.
• Easy and Smart – Link to your router via Bluetooth and set it up in minutes with the powerful Tether app.
• Battle-Tested Hardware - Equipped with 1.8 GHz Quad-Core CPU and 1 GB of RAM to handle huge throughput and crush the lag. Link Aggregation and USB 3.0 type C and type A ports ensure virtually any device can connect to your home network.
o 2-5 Gbps WAN Port
o 1-8 GHz Quad-Core CPU, 1GB RAM
o USB Type –A and USB Type-C
• Ready for Today and Tomorrow's Smart Home - With the growing number of devices in today's home, everyone deserves a smarter and easier way to bring all your products together. Utilize Amazon Alexa to control everything via voice commands to enjoy truly intelligent life.

HARDWARE FEATURES
• Processor: 1.8 GHz 64bit Quad-Core CPU
• Memory: 1 GB RAM and 512 MB Flash
• Interface:
o 8 x 1G/100M/10M LAN Ports,
o 1 x 2.5G/1G/100M WAN Port
o 1 x USB-A 3.0 Port
o 1 x USB-C 3.0 Port
• Button: Wi-Fi On/Off Button, Reset Button, WPS Button, Power On/Off Button, LED on/off
• External Power Supply: 12V/5A
• Antenna: 8 High-Performance External Antennas

WIRELESS FEATURES
• Wireless Standards:
o IEEE 802.11ax/ac/n/a 5 GHz
o IEEE 802.11ax/n/b/g 2.4 GHz
• Frequency: 2.4 GHz and 5 GHz
• Signal Rate:
o 5 GHz: 4804 Mbps(802.11ax)
o 5 GHz: 4804 Mbps(802.11ax)
o 2.4 GHz: 1148 Mbps(802.11ax)
o compatible with 802.11a/b/g/n/ac Wi-Fi standards
• Reception Sensitivity:
5 GHz1:
o 11a 6Mbps?-96dBm, 11a 54Mbps:-78dBm
o 11ac VHT20MCS0:-95dBm, 11ac VHT20MCS11:-65dBm
o 11ac VHT40MCS0:-93dBm, 11ac VHT40MCS11:-62dBm
o 11ac VHT80MCS0:-90dBm, 11ac VHT80MCS11:-59dBm
o 11ac VHT160MCS0:-87dBm, 11ac VHT160MCS11:-54dBm
o 11ax HE20MCS0:-94dBm, 11ax HE20MCS11:-62Bm
o 11ax HE40MCS0:-91dBm, 11ax HE40MCS11:-59dBm
o 11ax HE80MCS0:-88dBm, 11ax HE80MCS11:-57dBm
o 11ax HE160MCS0:-84dBm, 11ax HE160MCS11:-54dBm
5 GHz2:
o 11a 6Mbps?-96dBm, 11a 54Mbps:-78dBm
o 11ac VHT20MCS0:-95dBm, 11ac VHT20MCS11:-65dBm
o 11ac VHT40MCS0:-93dBm, 11ac VHT40MCS11:-62dBm
o 11ac VHT80MCS0:-90dBm, 11ac VHT80MCS11:-59dBm
o 11ac VHT160MCS0:-87dBm, 11ac VHT160MCS11:-54dBm
o 11ax HE20MCS0:-94dBm, 11ax HE20MCS11:-62Bm
o 11ax HE40MCS0:-91dBm, 11ax HE40MCS11:-59dBm
o 11ax HE80MCS0:-88dBm, 11ax HE80MCS11:-57dBm
o 11ax HE160MCS0:-84dBm, 11ax HE160MCS11:-54dBm
2.4 GHz?
o 11g 6Mbps?-97dBm, 11a 54Mbps:-79dBm
o 11n HT20MCS0:-97dBm, 11n HT20MCS7:-78dBm
o 11n HT40MCS0:-95dBm, 11n HT40MCS7:-75dBm
o 11ac VHT20MCS0:-96dBm, 11ac VHT20MCS11:-67dBm
o 11ac VHT40MCS0:-94dBm, 11ac VHT40MCS11:-64dBm
o 11ax HE20MCS0:-96dBm, 11ax HE20MCS11:-64dBm
o 11ax HE40MCS0:-93dBm, 11ax HE40MCS11:-61dBm
• Wireless Functions: Enable/Disable Wireless Radio, Guest network, DFS, MU-MIMO, OFDMA
• Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
• Transmission Power:
o CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.35GHz); <30dBm(5.47GHz~5.725GHz)
o FCC: <30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz), <24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz)
• Guest Network: 2.4 GHz guest network0 × 1, 5 GHz guest network × 1

SOFTWARE FEATURES
• Quality of Service: Advanced Gaming Qos powered by TrendMicro
• WAN Type: Dynamic IP/Static IP/PPPoE/PPTP/L2TP
• Management: Advanced Parental control powered by TrendMicro, Local Management, Remote Management
• DHCP: Server, DHCP Client List, Address Reservation
• Dynamic DNS: DynDns, NO-IP, TP-Link
• VPN: PPTP, OpenVPN
• Protocols: IPv4, IPv6
• NAT: Port Forwarding, Port Triggering, UPnP, DMZ

OTHER SPECIFICATIONS
• Certification: FCC, CE, RoHS
• System Requirements:
o Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
o NetWare, UNIX or Linux
o Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
o Java-enabled browser
o Cable or DSL Modem
o Subscription with an internet service provider (for internet access)
• Environment:
o Operating Temperature: 0?~40? (32? ~104?)
o Storage Temperature: -40?~70? (-40? ~158?)
o Operating Humidity: 10%~90% non-condensing
o Storage Humidity: 5%~90% non-condensing

What's in the box
1 x Wireless Router Archer AX11000
1 x Power Adapter
1 x RJ45 Ethernet Cable
1 x Quick Installation Guide
