ASUS ROG Rapture AX11000 Tri-band WiFi Gaming Router

ASUS ROG Rapture AX11000 Tri-band WiFi Gaming Router
ASUS GT-AX11000

• Triple-level Game Accelerator
• Battle-ready-hardware – 1.8GHz quad-core CPU and 2.5GBase -T port for ultimate performance.
• Front-line Network Security – Neutralize internet threats before they hit your network.
• Better Partner with Mesh System – Compatible with ASUS AiMesh Wi-Fi system for seamless whole-home coverage.

Specifications
Network Standard
- IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6

Product Segment
- AX11000 ultimate AX performance

Coverage
- Very Large homes

Data Rate
- 802.11ax (2.4GHz) : up to 1148 Mbps
- 802.11ax (5GHz) : up to 4804 Mbps

Antenna
- External antenna x 8

Transmit/Receive
- 2.4 GHz 4 x 4
- 5 GHz-1 4 x 4
- 5 GHz-2 4 x 4

Processor
- 1.8 GHz quad-core processor

Memory
- 256 MB Flash
- 1 GB RAM

Wi-Fi Technology
- OFDMA (Orthogonal Frequency Division Multiple Access)
- Beamforming: standard-based and universal
- 1024-QAM high data rate
- 20/40/80/160 MHz bandwidth

Operating Frequency
- 2.4G Hz, 5 GHz-1, 5 GHz-2

Encryption
- 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support

Firewall & Access Control
- Access control?Parental control, Network service filter, URL filter, Port filter

Management
- UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log

VPN Support
- IPSec Pass-Through
- PPTP Pass-Through
- L2TP Pass-Through
- PPTP server
- OpenVPN server
- PPTP client
- L2TP client
- OpenVPN client

WAN Connection Type
- Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP

Utilities
- Router setup wizard; Firmware restoration; Device discovary; printer setup utility

Ports
- RJ45 for BaseT for WAN x 1
- RJ45 for BaseT for LAN x 4
- Support Ethernet and 802.3 with max. bit rate 2.5Gbps Mbps and auto cross-over function(MDI-X)
- USB 3.1 Gen 1 x 2

Features
Link Aggregation
- 802.3ad
MU-MIMO
Traffic Analyzer
Adaptive QoS
WTFast Gamers Private Network
AiProtection Pro
Parental Control
Guest Network : 2.4 GHz x 3, 5 GHz-1 x 3, 5 GHz-2 x 3
VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server
VPN client : PPTP client, L2TP client, OpenVPN client
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
- Image : Jpeg
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
- Multifunctional printer support (Windows only)
- LPR protocol support
Download Master
- Support bt, nzb, http, ed2k
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
AiDisk file server
- Samba and FTP server with account management
Dual WAN
IPTV support
Roaming Assist

Button
- WPS Button, Reset Button, Power Button, Wireless on/off Button, Boost Key

LED Indicator
- Power x 1
- Wi-Fi x 2
- WAN x 1
- LAN x 1
- USB x 2
- WPS x 1
- 2.5G Port x 1

Power Supply
- AC Input : 110V~240V(50~60Hz)
- DC Output : 19 V with max. 3.42 A current

OS Support
- Windows 10
- Windows 8
- Windows 7
- Mac OS X 10.6
- Mac OS X 10.7
- Mac OS X 10.8

Operation mode
- Wireless router mode
- Access point mode
- Media bridge mode

Warranty
- 3 Years

Package Content
1 x GT-AX11000 Wi-Fi Router
1 x RJ-45 cable
1 x Power adapter
1 x QSG

What's in the box
1 x GT-AX11000 Wi-Fi Router
1 x RJ-45 cable
1 x Power adapter
1 x QSG
